Large Format 3D Printers: 300, 400 and 500 mm Options, and What Size Costs
LayerWalker is a participant in the Amazon Services LLC Associates Program. We may earn a commission when you buy through links on our site, at no extra cost to you.
Consumer large format runs from 300 mm (Creality K1 Max, Qidi Plus 4) through 350 mm (K2 Plus, SV08) and 400 mm (Ender-5 Max, Kobra 3 Max, Neptune 4 Max) to 500 mm (SV08 Max) and the 800 mm OrangeStorm Giga. Above 300 mm, frame type decides everything: CoreXY with a fixed bed prints large parts fast; a 400 mm bedslinger must crawl. Only the K2 Plus, Qidi Max 4 and Bambu H2 series are large and heated, so large ABS lives there.
Where to buy
The options by size
| Printer | Build volume | Frame | Enclosed | Nozzle | Amazon US |
|---|---|---|---|---|---|
| Creality K1 Max | 300 × 300 × 300 mm | CoreXY | Passive | 300 °C | Yes |
| Qidi Plus 4 | 305 × 305 × 280 mm | CoreXY | 65 °C heated | 370 °C | Yes |
| Bambu H2S | 340 × 320 × 340 mm | CoreXY | 65 °C heated | 350 °C | No |
| Creality K2 Plus | 350 × 350 × 350 mm | CoreXY | 60 °C heated | 350 °C | Yes |
| Sovol SV08 | 350 × 350 × 345 mm | CoreXY | Open (kit optional) | 300 °C | Yes |
| Qidi Max 4 | 390 × 390 × 340 mm | CoreXY | 65 °C heated | See listing | Yes |
| Creality Ender-5 Max | 400 × 400 × 400 mm | Cube, bed moves in Z | Open (optional) | 300 °C | Yes |
| Elegoo Neptune 4 Max | 420 × 420 × 480 mm | Bedslinger | Open | 300 °C | Varies |
| Anycubic Kobra 3 Max | 420 × 420 × 500 mm | Bedslinger | Open | 300 °C | Yes |
| Sovol SV08 Max | 500 × 500 × 500 mm | CoreXY | Open | 300 °C | Yes |
| Elegoo OrangeStorm Giga | 800 × 800 × 1000 mm | Bedslinger | Open | 300 °C | No |
What size costs
- Time. Volume scales with the cube. A 400 mm helmet at 0.2 mm layers with a 0.4 mm nozzle is a multi-day print; a 0.6 or 0.8 mm nozzle is not optional at this scale.
- Bed heating. A 400 mm bed to 60 °C takes minutes and real power.
- Materials. ABS over 300 mm warps without a heated chamber. Only the K2 Plus, Max 4 and H2 series are large and heated.
- Frame. Bedslingers over 300 mm sling kilograms; expect ringing and slow profiles. CoreXY wins at size.
Picks
- Large PLA and PETG, value: Sovol SV08 (tuning required) or Ender-5 Max. See SV08 and Ender-5 Max.
- Large ABS, nylon, PC: Creality K2 Plus or Qidi Max 4.
- Large and multi-colour: K2 Plus Combo or Kobra 3 Max Combo.
- Beyond 500 mm: the Giga, if you have the room; see the biggest printers.
The units in the box
The listings are the Ender-5 Max, the Kobra 3 Max Combo and the SV08 Max.
FAQ
Is 300 mm large format? It is the start of it; most helmets fit at 300 mm.
Do I need a 0.4 mm nozzle for large parts? No; 0.6 mm is the sensible default above 300 mm.
