Four ways to print two materials. IDEX: two independent carriages on one X axis (Sovol SV04, legacy); mirror and duplicate modes, but the second head idles most of the time. Fixed dual nozzle: two hotends on one carriage (Bambu H2D, X2D); no purge, some ooze management. Toolchanger: one carriage swaps whole heads (Prusa XL, INDX, Snapmaker U1); no purge, any nozzle mix. Single-nozzle AMS: cheapest, but purges on every change. In 2026 the toolchanger has won for serious multi-material.
Where to buy
The four architectures
| Architecture | How it works | Purge | Nozzle mix | Machines | Weak point |
|---|---|---|---|---|---|
| IDEX | Two carriages, independent X, shared Y | No | Yes | Sovol SV04, Flashforge Creator series (legacy) | Second head idle; alignment drift; heavy gantry |
| Fixed dual nozzle | Two hotends on one carriage, one lifts | No | Yes | Bambu H2D, X2D | Inactive nozzle can ooze; shared travel area |
| Toolchanger | One carriage docks and picks heads | No | Yes, 2 to 8 heads | Prusa XL, Prusa INDX, Snapmaker U1 | Cost; dock alignment; slower per swap than dual nozzle |
| Single nozzle + feeder | One hotend, filament swapped and purged | Yes | No | Bambu AMS, Creality CFS, Anycubic ACE, Qidi Box, MMU3 | Purge waste; time per change |
Why IDEX faded
IDEX was the hobby answer to dual material for a decade. It gives duplicate and mirror modes, printing two identical parts at once, which nothing else does. But the second carriage sits idle during most single-material prints, alignment between heads drifts, and the wide gantry limits speed. The Sovol SV04 is the last mainstream IDEX and is legacy; see the Sovol lineup.
Dual nozzle versus toolchanger
The Bambu H2D and X2D put two hotends on one carriage and lift the idle one. Swaps are near-instant and the machine stays compact, at the cost of a slightly smaller shared build area. A toolchanger docks heads, so it scales to five or eight tools and mixes nozzle sizes freely, but each swap takes seconds and the frame is larger. For two materials the dual nozzle wins on simplicity; for three or more, only a toolchanger does it without purge. See dual nozzle printers and the Prusa XL.
When single-nozzle is still right
Occasional multi-colour PLA. The purge cost is a nuisance, not a reason to buy a toolchanger. See AMS alternatives for every feeder system.
The units in the box
No current IDEX printer is on Amazon US. The listings are the Snapmaker U1 toolchanger, the Prusa XL with one toolhead, and the Bambu P2S Combo as the single-nozzle alternative.
FAQ
Can an IDEX print two parts at once? Yes, duplicate and mirror modes; toolchangers cannot.
Does the H2D print with both nozzles simultaneously? No; it alternates. The gain is no purge.
